| Model No. | Step Angle° | Current /Winding A |
Resistance /Phase Ω |
Inductance /Phase mH |
Weight Kg |
Length mm |
| Single Shaft | ||||||
| 42CA4(X)-2.33-ENG-E | 1.8 | 1.5 | 1.56 | 1.9±20% | 0.241 | 33.5 |
| 42NA4(X)-2.33-ENG-E | 1.8 | 1.5 | 1.56 | 1.9±20% | 0.241 | 33.5 |
| 42EA4(X)-2.33-ENG-E | 1.8 | 1.5 | 1.56 | 1.9±20% | 0.241 | 33.5 |
| 42CCA4(X)-2.33-ENG-E | 1.8 | 2.6 | 0.9 | 1.33±20% | 0.352 | 47.6 |
| 42NCA4(X)-2.33-ENG-E | 1.8 | 2.6 | 0.9 | 1.33±20% | 0.352 | 47.6 |
| 42ECA4(X)-2.33-ENG-E | 1.8 | 2.6 | 0.9 | 1.33±20% | 0.352 | 47.6 |
